$1,799.00
| /
Frame – Double Butted Aluminum
Fork- Double Butted Aluminum
Headset – FSA 1-1/8”
Wheelset – Shimano M-475
Tires – Kenda Kwick-Trax (700 x 38c)
Shifters – Shimano Alfine 8
Brakeset – Shimano
Rear Derailleur – Nexus 8 Internal Hub
Bottom Bracket – Real Speed Oversized External Cups
Crank- Gates Carbon X-Drive (46T)
Chain – Gates Carbon Belt
Cog – Gates 15T
Handlebar – Alloy Flat Bar
Stem – Alloy 31.6
Saddle – WTB Rocket
Seat post – Alloy 27.2
Tape: Ergo Grips
Make commuting the best part of your day. The Aquila B-Drive provides the perfect ratio strength and refinement to stand up to the rigors of the daily grind.
Simplistic as a single speed, but with gearing to tackle the city streets
|
|
XS |
S |
M |
L |
XL |
|
Seat Tube |
42CM |
44CM |
48CM |
52CM |
55CM |
|
Top Tube |
53CM |
55.5CM |
56.7CM |
57.7CM |
59CM |
|
Head Tube |
135MM |
145MM |
155MM |
175MM |
195MM |
|
Head Tube Angle |
69.5 |
70.5 |
71 |
71.5 |
72 |
|
Seat Tube Angle |
73.5 |
73.5 |
73 |
72.5 |
72.5 |
|
BB Drop |
60 |
60 |
60 |
60 |
60 |
|
Chain Stay Length |
456MM |
456MM |
456MM |
456MM |
456MM |
|
Wheel Base |
1072 |
1073 |
1074 |
1075 |
1080 |
|
Standover Height |
700MM |
735MM |
762MM |
821MM |
850MM |
|
Rider Height |
<164CM |
164-172CM |
170-177CM |
177-185CM |
185CM> |
